Capacity:
The vessel sits on four wheels: Full Load Capacity
Vessel Diameter Range is from 920 up to 2,800 mm.
Power Rotator Max Rotation Capacity: 10 MT
Power Rotator Max Load Capacity: 5 MT
Idler Rotator Max Load Capacity: 5 MT
The vessel sits on two bottom wheels: Half Load Capacity
Vessel Diameter Range is from 320 up to 900 mm.
Power Rotator Max Rotation Capacity: 5.00 MT
Power Rotator Max Load Capacity: 2.50 MT
Idler Rotator Max Load Capacity: 2.50 MT
Specifications:
Variable Speed: From 100 up to 1,000 mm/minute
Remote Control Box with 6 m cable:
Forward/Stop/Reverse/Variable speed adjustment with digital display in mm/min
Power: 1.10 kw
Wheel Diameter: 300 mm
Wheel Width: 170 mm
Estimated Weight: 1.20 MT
Warranty: One year
Operation Manual & Electric Diagram: Included
Delivery Time:
Within Canada: Three to five business days
USA & US-Mexican border: One week
Latino America: Four weeks
World-Wide: Five to six weeks
