Specifications:
Power Rotator Max Rotation Capacity: 100 MT
Power Rotator Max Load Capacity: 50 MT
Idler Rotator Max Load Capacity: 50 MT
Vessel Diameter Range: From 800 mm up to 7,800 mm
Variable Speed: From 100 up to 1,000 mm/minute
Remote Control Box with 6 m cable:
Forward/Stop/Reverse/Variable speed adjustment with digital display in mm/min
Power: 3.00 kW @ 2
Wheel Diameter: 500 mm
Wheel Width: 260 mm
Estimated Weight: 4.80 MT
Warranty: One year
Operation Manual & Electric Diagram: Included
Note: A combo of two sets of WR 100 (two powers + two idlers) can take 200 MT of load and rotation capacity.
Delivery Time:
Within Canada: Three to five business days
USA & US-Mexican border: One week
Latino America: Four weeks
World-Wide: Five to six weeks
