Irizar Heavy Industries Inc. is a Canadian company based in Edmonton. We take pride in manufacturing and stocking Welding Positioners, also known as Weld Positioners. These devices move the workpiece under the welding process equipment, whereas Welding Manipulators move the equipment over the workpiece. The Positioner offers powered 360° variable-speed rotation and table tilt, ranging from horizontal to 120°.
Load Capacity:
3.00 MT @ 300 mm GC
2.25 MT @ 400 mm GC
1.80 MT @ 500 mm GC
1.50 MT @ 600 mm GC
1.28 MT @ 700 mm GC
1.12 MT @ 800 mm GC
1.00 MT @ 900 mm GC
Specifications:
Eccentricity: 200 mm
Rotation speed: From 0.05 to 0.5 RPM
Tilt speed: From 0.23 RPM
Minimum Height: 1,380 mm
Maximum Height: 1,800 mm
Table diameter: 1,400 mm
Table with “T” shaped channels @ 45 degrees
Remote Control Box
Control Box: Forward/Stop/Reverse/Speed Adjustment with digital display
Foot control: Included
Max work piece diameter @ 90 degrees tilt: 2,100 mm
Tilt Angle: 0 to 120 degrees
Power Rotation: 1.50 kW
Power Tilt: 2.20 kW
Estimated Weight: 2.50 MT
Warranty: One year
Operation Manual & Electric Diagram: Included
NEW! ADJUSTABLE HEIGHT WELDING POSITIONER MODEL AH-WP 3
Delivery Time:
Within Canada: Three to five business days
USA & US-Mexican border: One week
Latino America: Four weeks
World-Wide: Five to six weeks
